S.S.Pumps



Stainless Steel Self Priming Pumps-(SS 316)
("SPS" Series Pumps)
Model HPxRPM PUMP SIZE TOTAL HEAD IN MTRS / DISCHARGE IN LPM
5 10 15 20 25 30 35 40 45 50 60 70 75
SPS-0 0.50x2900 12x12 18 18 17 14 7 1 - - - - - - -
SPS-1 0.50x2900 25x25 38 30 23 19 13   - - - - - - -
SPS-2 0.50x2900 25x25 35 25 21 17 9 7 3 - - - - - -
SPS-3 1.00x2900 25x25 49 49 45 39 36 27 19 - - - - - -
SPS-5 1.00x1450 25x25 65 57 48 42 35 27 21 3 - - - - -

Stainless Steel Self Priming Pumps-(316/304) 2800 RPM
("SCF" Series Pumps)
Model HPxRPM PUMP SIZE TOTAL HEAD IN MTRS / DISCHARGE IN LPM
4 6 8 10 12 14 16 18 20 22 24 26 28 30
SCF-1 0.25 12x12 25 26 17 14 - - - - - - - - - -
SCF-2 0.5 25x25 - - 112 108 80 70 - - - - - - - -
SCF-2A 0.5 40x40 - - 225 175 60 - - - - - - - - -
SCF-3 1 25x25 - - - - 140 130 122 100 95 80 70 30 - -
SCF-3A 1 40x40 - - 270 250 230 200 150 - - - - - - -
SCF-3B 1 50x50 - - 400 375 340 280 - - - - - - - -
SCF-4A 1.5 40x40 - - - - - - - - 160 150 130 90 - -
SCF-4B 1.5 50x40 - - - - 280 250 220 180 150 80 - - - -
SCF-5A 2 50x40 - - - - - - - - 230 200 186 130 - -
SCF-5B 2 50x50 - - - - 325 290 245 180 120 - - - - -
SCF-5C 2 80x80 - - 550 500 470 350 - - - - - - - -
Total in Mtr.(in Lpm) 6 8 12 16 20 24 28 32 36 40 45 48 54 56
SCF-6A 3 50x40 - - - - 230 200 180 150 75 - - - - -
SCF-6B 3 65x50 - - 575 520 265 225 - - - - - - - -
SCF-7A 5 50x40 - - - - - - - 260 230 190 145 90 - -
SCF-7B 5 65x50 - - - 650 580 520 300 210 150 - - - - -
SCF-7C 5 80x80 - - 1050 900 756 - - - - - - - - -
SCF-7D 5 10x100 1296 1120 1080 648 - - - - - - - - - -
SCF-7E 5 80x65 - - - 750 650 556 345 - - - - - - -
SCF-8A 7.5 50x40 - - - - - - - 290 280 250 225 190 120 60
SCF-8B 7.5 65x50 - - - - - 700 640 575 470 275 - - - -
SCF-8C 7.5 100x75 - - 1250 1150 950 800 - - - - - - - -
